Fowler 52-244-101-1, Ball Anvil And Ball Spindle 0-1" Measuring Range

The Fowler 52-244-101-1 Ball Anvil and Spindle Micrometer with 0-1" measuring range has a 0.256" diameter ball anvil/spindle pair for the measuring tube wall thickness, collars and sleeves. The vernier scale has 0.0001" graduation intervals and ± 0.00016″ accuracy for precise and accurate readings. The carbide-tipped anvil/spindle pair has hardened, precision-ground, and micro-lapped measuring faces for accurate measurements. This product has a 1-year warranty offered by Fowler High Precision. Fowler, an American company, manufactures premium inspection and measurement instruments like electronic indicators, calipers, bore gages, and micrometers. The company, founded in 1946, is headquartered in Canton, MA.

• Micrometer Gage: The micrometer features a ball anvil and spindle for the measuring of wall thickness of tubes, sleeves and collars at a single point.
• Accurate Measurements: Anvil and spindle hardened and precision ground with microlap carbide finish on tips; 0.256" diameter of measuring faces, 0.0001" graduation, and ± 0.00016" accuracy for precise readings
• Easy to Use: Quick, easy zero adjustment on the sleeve and positive lever locking clamp; ratchet stop thimble applies constant force for repeatability between users
• Satin Chrome Finish: Vernier scale with hammertone blue baked-enamel frame with heat-insulated frames; the finish on the thimble and sleeve helps reduce rust and glare, while the lapped spindle thread provides smooth movement, extending product life
• Set Includes: A ball-anvil tube micrometer, a wrench, and a fitted case
